PM 30
Chemical composition
| C | Cr | Mo | W | V | Co |
| 1.3 | 4.0 | 5.0 | 6.4 | 3.1 | 8.5 |
Typical applications
| Rack cutting (Broach) | Precision milling | Tapping |
|
Precision milling |
Cooling tools |
Deep hole |
| Europe | HS 6-5-3-8 |
| Germany | W.Nr.(1.3294) |
Delivery hardness
| Max 280HB |
Properties
PM30 is a kind of high cutting and cold ultra-pure powder metallurgical tool steel containing cobalt, which integrated high toughness and wear resistance, so it has excellent grinding performance. It is very suitable for different types of PVD coating.
| Supply size |
|
| Forging materials | Size range£¨mm£© |
| Round | 90-380 |
| Party/partial | Maximum width 450 |
|
|
Minimum thickness 40 |
| Rolled products |
|
| Skinning | 10-72 |
| The black board eraser | Thickness 5-55 |
|
|
Width 20-260 |
|
Special shapes |
As required |
|
PM module |
400*500*2100 |
|
|
400*600*1100 |
Annealing treatment
Cooling to 700¡æ slowly at a rate of 10¡æ/h under protective atmosphere of 850-900¡æ,then air cooling.
Strain relief
Keeping in 600-700¡æ for 2 hours, and cooling to 500¡æ slowly.
Quenching
Preheating in two steps under protective atmosphere, 400-500¡æ and 850-900¡æ, and choosing the right temperature depending on the hardness and then cooling of austenite to 40-50¡æ.
Tempering
560¡æ 3 times, each time for at least 1 hour, cooling to room temperature after each tempered.
